A
|
38062
|
Literature kit for 6 burner Summit LP, USA
|
|
|
A
|
38004
|
Assembly guide for 6 burner Summit Gold/Platinum
|
|
|
A
|
38026
|
Owners manual for 6 burner Summit LP, USA
|
|
|
E
|
41704
|
Hardware pack for Summit Silver/Gold grills - discontinued
|
|
|
1
|
88206
|
Hardware for lid assembly
|
|
|
2
|
60393
|
Thermometer w/o tab
|
|
|
2
|
67088
|
Lid Thermometer
|
Shop Now$21.99
|
|
3
|
67717
|
Bezel for Genesis/Summit, '07
|
|
|
4
|
41737
|
Swing-up basket for Summit, stainless steel
|
|
|
5
|
65619
|
Cooking Grates
|
Shop Now$101.99
|
|
5
|
85312
|
Cooking Grates
|
|
|
6
|
9897
|
Set of flavorizer bars for 6 burner Summit A/B
|
|
|
8
|
87403
|
1/4" Flat nylon washer, black
|
|
|
8
|
4086973
|
Hexhead bolt 1/4-20 x 1-1/4 inch.
|
|
|
9
|
97438
|
1/4-20 hex nut, stainless steel
|
|
|
10
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
10
|
67662
|
Crossover tube
|
|
|
11
|
67662
|
Crossover tube
|
|
|
11
|
85662
|
Burner Tube Kit
|
Shop Now$132.99
|
|
12
|
85662
|
Burner Tube Kit
|
Shop Now$132.99
|
|
13
|
85662
|
Burner Tube Kit
|
Shop Now$132.99
|
|
14
|
42542
|
Screw, 1/4-20x1/2 phillips trushead, black
|
|
|
15
|
82624
|
LP manifold for Summit Gold A/B
|
|
|
16
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
17
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
18
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
19
|
42053
|
Ignition switch, red button, for Summit Silver/Gold
|
|
|
19
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
20
|
42536
|
Plastic washer control panel mounting bracket for Summit Silver/Gold
|
|
|
20
|
42537
|
Screw, 10-24x1/2 phillips trushead, black
|
|
|
21
|
67683
|
Knob Kit
|
|
|
22
|
41703
|
Mounting clip for control panel
|
|
|
23
|
42118
|
Ignition decal for front panel
|
|
|
23
|
82666
|
Front panel, Summit Gold
|
|
|
24
|
82562
|
LHS work table, Summit Gold, '05
|
|
|
25
|
82715
|
Left trim, Summit Gold, '05
|
|
|
26
|
196
|
Hardware for trim pieces
|
|
|
27
|
87403
|
1/4" Flat nylon washer, black
|
|
|
28
|
4086958
|
Hexhead screw (bolt) 1/4-20 x 1/2 inch. Black.
|
|
|
32
|
99240
|
Door plugs and bushings
|
|
|
33
|
82569
|
Bottom panel, Summit Gold 6 burner, '05
|
|
|
34
|
67762
|
Hardware kit for bottom panel
|
|
|
35
|
99241
|
Locking Caster
|
Shop Now$9.99
|
|
36
|
60465
|
LHS door replacement, Summit 6 burner, '05
|
|
|
37
|
96015
|
Screw w/plastic washer, 10-16x3/4
|
|
|
38
|
4086935
|
Plastic plug for control panel, .250
|
|
|
39
|
43849
|
Door handles w/screws, stainless steel
|
|
|
40
|
60464
|
RHS door replacement, Summit 6 burner, '05
|
|
|
41
|
88206
|
Hardware for lid assembly
|
|
|
42
|
51410
|
Logo and fastener for Summit Gold grills
|
|
|
42
|
82561
|
Lid assembly, Summit Gold 6 burner, SS, '05
|
|
|
43
|
63728
|
Hex head screw, 1/4-20x3.25
|
|
|
43
|
60873
|
1/4 stainless steel washer
|
|
|
44
|
9897
|
Set of flavorizer bars for 6 burner Summit A/B
|
|
|
45
|
82575
|
Cookbox, Summit Gold A6/B6, '05
|
|
|
46
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
47
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
48
|
42244
|
Heat shield, Summit Gold
|
|
|
48
|
42181
|
Wire snap clip for Summit Silver/Gold, hi-temp
|
|
|
49
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
50
|
82616
|
Bulkhead assembly for Summit Silver C/Gold B/D LP
|
|
|
50
|
42535
|
Wing nut, 10-24 type D, black zinc
|
|
|
50
|
42536
|
Plastic washer control panel mounting bracket for Summit Silver/Gold
|
|
|
51
|
42057
|
Corrugated LP/NG gas line for Summit Silver/Gold, stainless steel
|
|
|
51
|
66496
|
Corrugated gas line, Genesis II LX 440/640
|
|
|
52
|
65941
|
QCC1 hose and regulator, Gold, Platinum, Silver
|
Shop Now$45.99
|
|
55
|
6498
|
Drip Pan
|
Shop Now$14.99
|
|
56
|
70379
|
Catch Pan Kit
|
Shop Now$25.99
|
|
57
|
82622
|
Rear frame connector for Summit Gold
|
|
|
58
|
42543
|
Side Burner LP Summit Silver grills 30mb
|
|
|
60
|
82718
|
Hardware for tank scale
|
|
|
61
|
78719
|
RHS wheel frame, Summit, painted. '05
|
|
|
63
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
64
|
92177
|
Tank scale lock bracket
|
|
|
64
|
99243
|
Tank scale
|
|
|
64
|
87901
|
Wing nut 1/4-20 inch. Black.
|
|
|
65
|
82716
|
Right trim, Summit Gold B/C/D, '05
|
|
|
66
|
90209
|
Bracket for right hand side swing up table. For Genesis-B and Genesis-C grills.
|
|
|
67
|
80313
|
Tank glide buttons
|
|
|
68
|
82607
|
Door stop for Summit Silver/Gold
|
|
|
69
|
99240
|
Door plugs and bushings
|
|
|
70
|
78714
|
Hinge rod for Summit doors, '05
|
|
|
71
|
42040
|
Match holder
|
|
|
410
|
38004
|
Assembly guide for 6 burner Summit Gold/Platinum
|
|
|
410
|
38026
|
Owners manual for 6 burner Summit LP, USA
|
|
|
410
|
38062
|
Literature kit for 6 burner Summit LP, USA
|
|
|
470
|
41704
|
Hardware pack for Summit Silver/Gold grills - discontinued
|
|
|
470
|
80313
|
Tank glide buttons
|
|
|
470
|
82718
|
Hardware for tank scale
|
|
|
480
|
42325
|
Igniter kit for Summit Gold B/B6
|
|
|
510
|
9971
|
Rotisserie for 6-burner Summit grill models
|
|
|
510
|
6498
|
Drip Pan
|
Shop Now$14.99
|
|
510
|
7516
|
Grill Out Handle Light for Spirit/Genesis/Summit
|
|
