A
|
86020
|
Owners manual for Genesis 5000 Gas Grill with natural gas connection. USA.
|
|
|
1
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
1
|
60582
|
Lid assembly, Genesis/Spirit, black
|
|
|
1
|
60542
|
Lid assembly, Genesis B, mica black, SS handle
|
|
|
1D
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
1F
|
90501
|
Weber logo label and fasteners
|
|
|
1I
|
4086950
|
Screw #8-32x3/8 inch hex head.
|
|
|
1L
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
2
|
80632
|
Warming Rack
|
Shop Now$47.99
|
|
3
|
80633
|
Warming Rack
|
Shop Now$47.99
|
|
5
|
48968080
|
Smoker flue, enameled - discontinued
|
|
|
7
|
65901
|
Set of SS Flavorizer Bars, Genesis 1-5500
|
|
|
8
|
65901
|
Set of SS Flavorizer Bars, Genesis 1-5500
|
|
|
9
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
9
|
1174100
|
Porcelain enameled cooking grate, Genesis Jr. & also used with smoker attachment (Qty 1)
|
|
|
10
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
14
|
4086928
|
Tubing plug, black
|
|
|
15
|
4086974
|
Hexhead bolt 1/4-20 x 2 inch. Black.
|
|
|
17
|
33001
|
End bracket for swing table manufactured in 1993 through 1998.
|
|
|
19
|
4086958
|
Hexhead screw (bolt) 1/4-20 x 1/2 inch. Black.
|
|
|
20
|
87403
|
1/4" Flat nylon washer, black
|
|
|
22
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
22A
|
4886971
|
Slide lock swing-up table (qty. 1)
|
|
|
22B
|
85911
|
Support rod for Genesis 2-5500 for swing table assembly.
|
|
|
23
|
4886969
|
Screw 10-24 x 1-3/4 inch.
|
|
|
24
|
86901
|
10/24-inch hexagonal nut
|
|
|
27
|
65936
|
Caster w/insert, qty. 1
|
|
|
28
|
99253
|
Catch Pan Holder
|
Shop Now$24.99
|
|
29
|
93305
|
Catch Pan Kit
|
Shop Now$14.99
|
|
30
|
6415
|
Drip Pans
|
Shop Now$10.99
|
|
31D
|
4986979
|
Screw, 6-32 x 1/4, philips head black
|
|
|
32D
|
4986979
|
Screw, 6-32 x 1/4, philips head black
|
|
|
35
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
36
|
63050
|
Wheel
|
|
|
41
|
87503
|
Hex nut 1/4-20 inch, zinc
|
|
|
42
|
87901
|
Wing nut 1/4-20 inch. Black.
|
|
|
43
|
4786980
|
Side burner lock
|
|
|
46
|
4086955
|
Hexhead bolt 1/4-20 x 1-1/2 inch.
|
|
|
47
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
47A
|
4886971
|
Slide lock swing-up table (qty. 1)
|
|
|
47B
|
85911
|
Support rod for Genesis 2-5500 for swing table assembly.
|
|
|
48
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
49
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
50
|
62538
|
Lid Thermometer
|
Shop Now$10.99
|
|
51
|
1309
|
Hex nut 1/4 x 20 inch Keps nut
|
|
|
52A
|
97783
|
Bottom tray rails w/hardware
|
|
|
53
|
67672
|
Knob Kit
|
Shop Now$39.99
|
|
56
|
92510
|
Rocker switch. Grey. (1996-present).
|
|
|
57
|
668
|
Control panel plugs with screws. 1/4-inch.
|
|
|
58
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
59
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
60
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
61
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
63
|
4089600
|
Manifold bracket for Genesis and Platinum series gas grills
|
|
|
65
|
6021713
|
NUT M8 X 1 HEX BRASS
|
|
|
65
|
20201822
|
Thermocouple nut
|
|
|
66
|
99835
|
Tool holder (qty. 1)
|
|
|
66
|
2402639
|
TOOL HOLDER GEN BB
|
|
|
68
|
900
|
Igniter kit for Genesis, Spirit and Platinum model year 2000 grills.
|
Shop Now$18.99
|
|
68A
|
48826420
|
Igniter switch (includes push button)
|
|
|
68B
|
40826414
|
Igniter installation nut.
|
|
|
68E
|
70643
|
Ignition chamber assembly, 02
|
|
|
72
|
99263
|
Hose
|
Shop Now$84.99
|
|
72
|
42140
|
Quick disconnect for natural gas hose, 3/8" (connector only)
|
|
|
72
|
872103
|
10-foot natural gas hose
|
|
|
410
|
39906
|
Instruction sheet for ignition chamber.
|
|
|
410
|
86020
|
Owners manual for Genesis 5000 Gas Grill with natural gas connection. USA.
|
|
|
410
|
4736910
|
Instruction sheet for adding the Side burner.
|
|
|
410
|
55355
|
Instruction sheet for burner tube replacement, `02
|
|
|
410
|
97029
|
Instruction sheet for smoker for Summit 400-675
|
|
|
410
|
39919
|
Instruction sheet for flamecheck installation/maintenance.
|
|
|
410
|
96276
|
Instruction sheet for adding a swing up table to the left or right-hand side.
|
|
|
460
|
33001
|
End bracket for swing table manufactured in 1993 through 1998.
|
|
|
460
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
460
|
3627
|
Durawood work table with spacer bracket
|
|
|
460
|
63180
|
Spacer bracket. Painted.
|
|
|
460
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
460
|
3626
|
Discontinued - Durawood swing table with hardware, LHS
|
|
|
460
|
62619
|
Instruction sheet for Durawood spacer.
|
|
|
460
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
470
|
668
|
Control panel plugs with screws. 1/4-inch.
|
|
|
470
|
97783
|
Bottom tray rails w/hardware
|
|
|
470
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
470
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
470
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
470
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
480
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
480
|
900
|
Igniter kit for Genesis, Spirit and Platinum model year 2000 grills.
|
Shop Now$18.99
|
|
490
|
9861
|
SS cooking grates, Genesis 4-5500/Platinum B-C
|
|
|
490
|
1174100
|
Porcelain enameled cooking grate, Genesis Jr. & also used with smoker attachment (Qty 1)
|
|
|
490
|
7639
|
Cooking Grates
|
Shop Now$150.99
|
|
490
|
65906
|
Cooking Grates
|
Shop Now$62.99
|
|
490
|
7638
|
Cooking Grates
|
|
|
490
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
495
|
9813
|
Porcelain enamel flavorizer bars for Genesis series grills.
|
|
|
495
|
7538
|
Flavorizer Bars
|
Shop Now$127.99
|
|
510
|
7659
|
Rotisserie - Spirit 200/300/500/700, Genesis Silver/Gold/Plat/1000-5500
|
|
|
510
|
80632
|
Warming Rack
|
Shop Now$47.99
|
|
510
|
62104
|
Weber Grill Out Handle Light - Rectangle Bracket
|
|
|
515
|
78964
|
Control knob for Genesis Silver-C and Gold-C side burners
|
|
|
515
|
47875600
|
Control knob (grey) for the Side burner.
|
|
|
515
|
4736910
|
Instruction sheet for adding the Side burner.
|
|
|
516
|
86915
|
Screw #10 x 3/4 Phillips Pan Head
|
|
|
516
|
4786952
|
Fastener, Tinnerman.
|
|
|
517
|
92510
|
Rocker switch. Grey. (1996-present).
|
|
|
518
|
47997815
|
Bottom Sideburner, black. Two-slot.
|
|
|
521
|
48826420
|
Igniter switch (includes push button)
|
|
|
521
|
63117
|
Igniter kit for the Sideburner.
|
|
|
522
|
63117
|
Igniter kit for the Sideburner.
|
|
|
522
|
40826418
|
Igniter rubber washer
|
|
|
523
|
40826414
|
Igniter installation nut.
|
|
|
523
|
63117
|
Igniter kit for the Sideburner.
|
|
|
525
|
4786955
|
Plastic hinge for side burner cover. Black. (Qty 1)
|
|
|
528
|
4786980
|
Side burner lock
|
|
|
529
|
4786971
|
Spider guard for the Side burner.
|
|
|
531
|
47826421
|
Igniter electrode for the Side burner.
|
|
|
531
|
63117
|
Igniter kit for the Sideburner.
|
|
|
533
|
63117
|
Igniter kit for the Sideburner.
|
|
